Motorised Workbenches with Tiltable Frame

Description

Gigant Flex Combi is a work table where adjustment of the working height and angle is a must. For example, for ergonomic and rational assembly of equipment cabinets.
Flex Combi is manufactured in two designs both with a tiltable, motorised working area 0 - 70 degrees.

Single post system - 100 kg distributed load.
Duo post system - 200 kg distributed load.

Supplied excl. worktop.

Frame with posts of natural anodized aluminium and with heavy-duty bearings. High stability on account of the fully welded, square section steel frames.
Base and top arm are powder coated. Foot frame with 4 lockable castors.
The lower edge of the work area is variably adjustable, on Flex Combi Duo also the top. The lower edge also acts as a support and protective edge. Protective edge, height 70 mm, also creates space for tools.
The frame is connected to 230 V/50 Hz and is supplied with a hand controller for height setting.

Frames in other sizes and designs quoted on request.

Flex Combi - Single post max. load 100 kg
*Art. no.*	*13024*	-0104	-0203
Design		Grey	ESD, Grey
Worktop frame length x depth	mm	1200 x 1200	1200 x 1200
Max. working area, length x depth	mm	1500 x 1200	1500 x 1200
Adjustable height excl. worktop	mm	790-1290	790-1290
Height adjustment/speed, unloaded	mm/s	25	25
Max. load	kg	100	100
Flex Combi - Duo post max. load 200 kg
*Art. no.*	*13024*	-0302	-0401
Design		Grey	ESD, Grey
Worktop frame length x depth	mm	1200 x 1200	1200 x 1200
Max. working area, length x depth	mm	1800 x 1200	1800 x 1200
Adjustable height excl. worktop	mm	790-1290	790-1290
Height adjustment/speed, unloaded	mm/s	25	25
Max. load	kg	200	200
